Pipedata-Plus v2164

Pipedata-Plus has dimensional and weight information for over 160 common piping components with the addition of specialties such as strainers, weldoflanges etc. Pipedata-Plus also includes the design aids, safe spans, pipe flexibility, spacing and more. The interface is enhanced with color coded components and parameters.

Based on the latest ASME piping dimensional specifications it shows Metric, U.S. Customary Units and Inch Fractions, NPS and DN pipe sizes and includes audited valve weights, flange weights, pipe weights and all piping component weights.

DATA SUMMARY
Pipedata Provides
Piping Dimensions and Weights
Flange Dimensions and Weights
Valve Dimensions and Weights
Piping Fittings Dimensions and Weights
for the following components:

FLANGES
ASME B16.5 Flanges
WeldNeck Flange
Slip On Flange
Blind Flange
Threaded Flange
SocketWeldedFlangeLapped Flange
Long Welding Neck Flange

ASME B16.47 Series A Flanges
WeldNeck Flange
Blind Flange

ASME B16.47 Series B Flanges
WeldNeck Flange
Blind Flange

Orifice Flanges ASME B16.36
WeldNeck
Slip On
Threaded

API-6A Flanges
API Type 6B
Weldneck
Threaded Flange
Blind

API Type 6BX
WeldNeck
Blind and Test Flange

Reducing Flanges AMSE B16.5
Threaded
Slip-On

ASME Compact Flanges
Standard
Swivel
Blind

Hub and Clamp
Hub-Clamp Pipe Connector

Din Flanges EN1092-1:2013
Blind Flange
Threaded Flange
Flat Flange
Weldneck Flange
Lapped Flange

BS 10 Flanges
TABLES A,D,E,F,H,J,K.R& S

VALVES
ASME B16.10
Flanged Valves
Gate Valve
Globe Valve
Ball Valve
Control Valve (for layout)
Swing Check
Wafer Check
Wafer type Butterfly
Lug type Butterfly

Buttwelded Valves
Gate
Globe
Ball Valve
Check

Threaded Valves
Gate
Globe
Horizontal Check
Vertical Check

Socketwelded Valves
Gate
Globe
Horizontal Check
Vertical Check

BLINDS AND SPACERS
ASME B16.48
Spectacle Blind
Line Spade and Spacer
RTJ Male Type Reversible Spade
RTJ Male Type Line Spade

WELDED BRANCHES
Olets
ButtWelded
Threaded
SocketWelded
Weldoflange
Elbowflange
Latroflange
Nipoflange

GASKETS
None Metallic Flat Ring for ASME B16.5 Flanges
None Metallic Flat Ring for ASME B16.47 Series A Flanges
None Metallic Flat Ring for ASME B16.47 Series B Flanges
Spiral wound for ASME B16.5 Flanges
Spiral wound for ASME B16.47 Series A Flanges
Spiral wound for ASME B16.47 Series B Flanges
RTJ soft iron ring type R - ASME B16.21
RTJ soft iron ring type RX - ASME B16.21
RTJ soft iron ring type BX - ASME B16.21

PIPE FITTINGS
ASME B16.9 and ASME B16.11
Butt Welded
Threaded
Socket Welded

PIPE
ASME B16.10M/19M
Pipe By Schedule
Pipe By Wall Thickness

NUTS
ISO Nuts
UNC Nuts

DESIGN AIDS
ASME Composite Dimensions
Pipe Flexibility
Pipe Leg
Pipe Loop
Safe spans
Safe rack spans
Safe Pipe Spacing
Safe Pipe Spacing with Insulation
Safe Flanged Pipe Spacing
Safe Flanged Pipe Spacing With Insulation
